Geomembrane

A ProFlex geomembrane is ideal for most applications and major benefits to installation are provided by lower coefficient of thermal expansion and a wide temperature-welding window.

ProFlex is a propylene/ethylene copolymer geomembrane produced from a resin formulation designed to provide quality geomembrane with excellent flexibility, and improved elasticity and resistance to puncture. These properties assure maximum multiaxial elongation to accommodate differential settlement. ProFlex is ideal for most geomembrane applications and major benefits to installation are provided by lower coefficient of thermal expansion and a wide temperature-welding window.

GEOMEMBRANE PRODUCT SPECIFICATION
Tested property Test method Frequency Minimum average value
0.75 mm 1.00 mm 1.50 mm 2.00 mm
Thickness, mm
Lowest individual reading (-10%)
ASTM D 5199 2,000 kg 0.75
0.68
1.00
0.90
1.50
1.35
2.00
1.80
Density, g/cm3 (max.) ASTM D 1505 7,500 kg 0.87 0.87 0.87 0.87
Tensile Properties (each direction)
Strength at Break, N/mm
Elongation at Break, %
ASTM D 6693, Type IV
Dumbbell, 500 mm/min
G.L. 50 mm
7,500 kg 12
900
17
900
25
900
35
900
Tear Resistance, N ASTM D 1004 7,500 kg 45 55 90 100
Puncture Resistance, N ASTM D 4833 7,500 kg 120 150 200 300
REFERENCE PROPERTY TEST METHOD FREQUENCY NOMINAL VALUE
Carbon Black Content, % (Range) ASTM D 1603*/4218 3.0 3.0 3.0 3.0
Carbon Black Dispersion ASTM D 5596 Note(1) Note(1) Note(1) Note(1)
Mulit-axial Strain, % ASTM D 5617 > 120 > 120 > 120 > 120
Low Temperature Brittleness, °C ASTM D 2136(2) < -40 < -40 < -40 < -40
TYPICAL ROLL DIMENSIONS
Roll Length(3), m 341 265 171 131
Roll Length(3), m 6.9 6.9 6.9 6.9
Roll Area, m2 2,341 1,819 1,171 899
These product specifications meet GRI GM18 NOTES
(1) Dispersion only applies to near spherical agglomerates. 9 of 10 views shall be Category 1 or 2. No more
than 1 view from Category 3. (2) Using 32mm mandrel 4 hours. (3) Roll lengths and widths have a tolerance
of ±1%. ProFlex is available in rolls weighing approximately 1,769 kg. *Modified.



Geotextile

A mechanically bonded nonwoven geotextile that demonstrates a high tensile and CBR to offer an element of protectionin addition to the standard requirements of separation and filtration. A heavier weight geotextile with both mechanical and hydraulic properties to address the more demanding end of the separation/filtration market and start of the membrane protection market.In applications such as attenuation SUDS systems or small pond/lagoon applications, it offers effective protection of the impermeable liner.

Technical Data
Test Standard 80 100 200 300
Tensile Strength(kN / m) EN 10319 MD 6 8 18 25
CD 6 8 18 25
Elongation at max. load (%) EN 10319 MD 36 45 50 65
CD 42 45 50 65
CBR Puncture Resistance (N) EN ISO 12236 1050 1500 2900 4300
Cone Drop Penetration
(mm)
EN 13433 48 36 18 13
Pore Size 90% finer than
(microns)
EN ISO 12956 128 100 70 70
Water Permeability
(m / sec)
EN ISO 11058 144×10-3 130×10-3 80×10-3 65×10-3
Effect of UV Light The Polypropylene used contains a UV inhibitor
Weight (g/m2) 80 100 200 300
Roll Size Width 4.5 4.5 4.5 4.5
Length 100 100 100 50/100



Gas Barrier

Our Gas Barrier is a multi-layer, low density polyethylene membrane, reinforced with a polypropylene reinforcing grid with an integral aluminium foil. Our Gas Barrier is specifically designed and manufactured to perform as a Methane, Carbon Dioxide, Radon, Ground Gas, VOC/Hydrocarbon vapours, air & moisture protection system.

Our Gas Barrier

Characteristics

Test Method

Unit

Our Gas Barrier

Physical Properties

Thickness

EN 1849-2

mm

0.6

Thickness – Between Scrim

Micrometre

Mm

0.4

Width

EN 1849-2

m

Various

Length

EN 1849-2

m

Various

Weight

EN 1849-2

G/M2

370

Hydraulic Properties

 Water column  EN 20811  –  >300
 Resistance to Water Penetration  EN 13967, EN 1928  –  Pass

Water Tightness

EN 1296, EN 1367, EN 1928

Pass

Hydraulic Properties

Resistance to Static Load

EN 12730-B

Kg

20

Tensile Strength (MD)

EN 12311-1

N/50mm

600

Tensile Strength (CMD)

EN 12311-1

N/50mm

480

Tensile Elongation (MD)

EN 12310-1

%

20

Tensile Elongation (CMD)

EN 12310-1

%

20

Puncture Resistance

EN 12236

kN

1.25

Resistance to Tearing (Nail Shank) MD

EN 12310-1

N

330

Resistance to Tearing (Nail Shank) CMD

EN 12310-1

N

400

Durability and Chemical Resistance

Transmission Rate of Volatile Liquids – Diesel

ISO 6179:2010 (B)

g/m2/h

0.246

Transmission Rate of Volatile Liquids – Xylene

ISO 6179:2010 (B)

g/m2/h

0.571

Transmission Rate of Volatile Liquids – Toluene

ISO 6179:2010 (B)

g/m2/h

0.583

Transmission Rate of Volatile Liquids – Petrol

ISO 6179:2010 (B)

g/m2/h

0.135

Gas Permeability

Methane Permeability

BS EN ISO 15105-1

ml/m2/day/atm

<0.09

Carbon Dioxide Permeability

BS EN ISO 15105-1

ml/m2/day/atm

<0.09

Radon Permeability

K124/02/95

m2/s

8.0 x 10-15

Compliance and Certification

CE Mark – EN13967:2012

NHBC Standards Compliant

BS 8485:2015 Compliant

BBA Certified – Certificate No. 12/4912
